- RS-422/485 Repeator
- 2kV, 3-way isolation (input/output/power)
- Data rates:1.2 to 115.2 Kbps
- Wide operating temperature range: -40 to +85 °C
- IEC-61850-3, IEEE-1613, NEMA TS2, FCC, CE
- 10 to 48 VDC input power (power supply required, sold separately)
Model BB-485OPDRI-PH is a premium, heavy industrial RS-422/485 isolated repeater. Designed for rugged industrial environments, it meets some of the most exacting compliance tests in the industry. IEC 61850-3 and IEEE 1613 rated, it is suitable for installation in electrical substations. (These specifications are more stringent than NEMA TS1/TS2 requirements for transportation applications).
Powerful isolation on both data ports protects your equipment and data from damaging ground loops and surges. Additional isolation on the power supply circuits adds a third degree of protection.
Packaged in a rugged IP30 metal case, it extends full or half-duplex RS-422/485 signals an additional 4000 feet and allows you to add another 32 nodes to your network. Bit-wise enabled circuitry automatically detects the data rate without setting a DIP switch.
10-48 VDC power is externally sourced (power supply required, not included, sold separately).
제품특징 제품 사양 다운로드
- Part Number
- 제품 상세
-
BB-485OPDRI-PH
- Technology
- Mounting
- Power
- Temperature
- Isolation
- Power and Data Isolated
- Serial Type
- Serial
- Panel
- 10-48VDC
- -40 to 85C
- 2kV
- Yes
- RS-422/485
- Serial Standard
- Maximum Serial Transmission Speed
- Serial Port Connector Type
- Serial Port Number
- Repeater Maximum Distance
- RS-422 / RS-485
- 115.2 Kbps
- Terminal block
- 1
- 1.2 Kilometers
- Temperature (Operating Range)
- -40 ~ 85°C (-40 ~ 185°F)
- Isolation
- Surge Protection
- 2,000 VDC
- 600W
- Safety
- Substation
- UL C1/D2 (Class I, Division 2)
- IEC-61850-3
- Power Input (DC)
- 10 ~ 48 VDC
- Mounting
- Panel
- Enclosure (Metal)
- Metal
General
-
Technology
BB-485OPDRI-PH Serial -
Mounting
BB-485OPDRI-PH Panel -
Power
BB-485OPDRI-PH 10-48VDC -
Temperature
BB-485OPDRI-PH -40 to 85C -
Isolation
BB-485OPDRI-PH 2kV -
Power and Data Isolated
BB-485OPDRI-PH Yes -
Serial Type
BB-485OPDRI-PH RS-422/485
Serial Communication
-
Serial Standard
BB-485OPDRI-PH RS-422 / RS-485 -
Maximum Serial Transmission Speed
BB-485OPDRI-PH 115.2 Kbps -
Serial Port Connector Type
BB-485OPDRI-PH Terminal block -
Serial Port Number
BB-485OPDRI-PH 1 -
Repeater Maximum Distance
BB-485OPDRI-PH 1.2 Kilometers
Environment
-
Temperature (Operating Range)
BB-485OPDRI-PH -40 ~ 85°C (-40 ~ 185°F)
Protection
-
Isolation
BB-485OPDRI-PH 2,000 VDC -
Surge Protection
BB-485OPDRI-PH 600W
Certification
-
Safety
BB-485OPDRI-PH UL C1/D2 (Class I, Division 2) -
Substation
BB-485OPDRI-PH IEC-61850-3
Power
-
Power Input (DC)
BB-485OPDRI-PH 10 ~ 48 VDC
Accessory General
-
Mounting
BB-485OPDRI-PH Panel
Mechanism
-
Enclosure (Metal)
BB-485OPDRI-PH Metal
