- Intel® Atom™ E3815/E3825 processor with 4GB DDR3L onboard memory
- 2 x GbE, 1 x USB 3.0, 1 x HDMI, Option 2 x RS-232/422/485 or 3 x USB2.0
- Compact Fanless Design and Rubber Stopper Design with internal reserved screws for 2nd layer assembly
- Diverse system I/O and Isolated Digital I/O by iDoor Technology
- Supports Fieldbus Protocol by iDoor Technology
- 3G/GPS/GPRS/Wi-Fi communication by iDoor technology
- Supports 30+ iDoor combination with four main categories of smart factory applications
- 32GB eMMC storage onboard
- RED Compliance for LTE solution
Advantech new generation UNO-2000 series of embedded automation computers are highly ruggedized, fanless, and modular designs. New UNO-2000 series includes pocket, small,and regular-sized form-factors for different kinds of smart factory applications such as Equipment Connectivity (EC), Process Visualization (PV), Environment Management (EM), and Dispatch Management (DM).The modular design of UNO- 2271G features optimized I/O and offers three different configurations. It also supports Advantech’s iDoor technology via a second expansion stack. UNO-2000 series provide flexible and time-to-market support for a variety of applications.
Product Specifications (6) Download Spec
- Part Number
- Details
-
UNO-2271G-E21BE
-
UNO-2271G-E22BE
-
UNO-2271G-E23BE
-
UNO-2271G-E021AE
-
UNO-2271G-E022AE
-
UNO-2271G-E023AE
- Ingress Protection
- Operating Temperature
- Relative Humidity
- Shock Protection
- Storage Temperature
- Vibration Protection
- IP30
- IP30
- IP30
- IP30
- IP30
- IP30
- 0~50 °C (32~122 °F)
- 0~50 °C (32~122 °F)
- 0~50 °C (32~122 °F)
- 0~50 °C (32~122 °F)
- 0~50 °C (32~122 °F)
- 0~50 °C (32~122 °F)
- 10~95% RH (non-condensing)
- 10~95% RH (non-condensing)
- 10~95% RH (non-condensing)
- 10~95% RH (non-condensing)
- 10~95% RH (non-condensing)
- 10~95% RH (non-condensing)
- 50 G, half sine
- 50 G, half sine
- 50 G, half sine
- 50 G, half sine
- 50 G, half sine
- 50 G, half sine
- -20~70 °C (-4~158 °F)
- -20~70 °C (-4~158 °F)
- -20~70 °C (-4~158 °F)
- -20~70 °C (-4~158 °F)
- -20~70 °C (-4~158 °F)
- -20~70 °C (-4~158 °F)
- 2 Grms, random
- 2 Grms, random
- 2 Grms, random
- 2 Grms, random
- 2 Grms, random
- 2 Grms, random
- Certification
- CPU
- Graphics Engine
- Memory
- OS Support
- Power Input
- Storage
- CE, FCC, UL, CCC, BSMI
- CE, FCC, UL, CCC, BSMI
- CE, FCC, UL, CCC, BSMI
- CE, FCC, UL, CCC, BSMI
- CE, FCC, UL, CCC, BSMI
- CE, FCC, UL, CCC, BSMI
- Intel® ATOM E3815 1.46GHz Single-Core
- Intel® ATOM E3815 1.46GHz Single-Core
- Intel® ATOM E3815 1.46GHz Single-Core
- Intel® Celeron E3825 1.33 Ghz Dual-Core
- Intel® Celeron E3825 1.33 Ghz Dual-Core
- Intel® Celeron E3825 1.33 Ghz Dual-Core
- Intel® HD Graphics
- Intel® HD Graphics
- Intel® HD Graphics
- Intel® HD Graphics
- Intel® HD Graphics
- Intel® HD Graphics
- 1 x Onboard Memory with 4 GB DDR3L 1066 MHz
- 1 x Onboard Memory with 4 GB DDR3L 1066 MHz
- 1 x Onboard Memory with 4 GB DDR3L 1066 MHz
- 1 x Onboard Memory with 4 GB DDR3L 1066 MHz
- 1 x Onboard Memory with 4 GB DDR3L 1066 MHz
- 1 x Onboard Memory with 4 GB DDR3L 1066 MHz
- Microsoft® Windows 10 2019 LTSC, WES7, Linux
- Microsoft® Windows 10 2019 LTSC, WES7, Linux
- Microsoft® Windows 10 2019 LTSC, WES7, Linux
- Microsoft® Windows 10 2019 LTSC, WES7, Linux
- Microsoft® Windows 10 2019 LTSC, WES7, Linux
- Microsoft® Windows 10 2019 LTSC, WES7, Linux
- 10~30 VDC
- 10~30 VDC
- 10~30 VDC
- 10~30 VDC
- 10~30 VDC
- 10~30 VDC
- 32 GB eMMC, 1 x mSATA (shared with mPCIe)
- 32 GB eMMC, 1 x mSATA (shared with mPCIe)
- 32 GB eMMC, 1 x mSATA (shared with mPCIe)
- 32 GB eMMC, 1 x mSATA (shared with mPCIe)
- 32 GB eMMC, 1 x mSATA (shared with mPCIe)
- 32 GB eMMC, 1 x mSATA (shared with mPCIe)
- Displays
- Expansion
- LAN Ports
- Power Connector
- USB Ports
- Serial Ports
- 1 x HDMI
- 1 x HDMI
- 1 x HDMI
- 1 x HDMI
- 1 x HDMI
- 1 x HDMI
- 1 x Full-size mPCIe Slot
- 1 x Full-size mPCIe Slot
- 1 x Full-size mPCIe Slot
- 1 x Full-size mPCIe Slot
- 1 x Full-size mPCIe Slot
- 1 x Full-size mPCIe Slot
- 2 x 10/100/1000 Mbps
- 2 x 10/100/1000 Mbps
- 2 x 10/100/1000 Mbps
- 2 x 10/100/1000 Mbps
- 2 x 10/100/1000 Mbps
- 2 x 10/100/1000 Mbps
- 1 x 2-Pin Terminal Block
- 1 x 2-Pin Terminal Block
- 1 x 2-Pin Terminal Block
- 1 x 2-Pin Terminal Block
- 1 x 2-Pin Terminal Block
- 1 x 2-Pin Terminal Block
- 1 x USB 3.0
- 3 x USB 2.0, 1 x USB 3.0
- 1 x USB 3.0
- 1 x USB 3.0
- 3 x USB 2.0, 1 x USB 3.0
- 1 x USB 3.0
- -
- -
- 2 x RS 232/422/485
- -
- -
- 2 x RS 232/422/485
- Dimension (W x H x D)
- Enclosure
- Weight (Net)
- 100 x 70 x 30 mm
- 100 x 70 x 60 mm
- 100 x 70 x 60 mm
- 100 x 70 x 30 mm
- 100 x 70 x 60 mm
- 100 x 70 x 60 mm
- Aluminum housing
- Aluminum housing
- Aluminum housing
- Aluminum housing
- Aluminum housing
- Aluminum housing
- 0.5 kg (1.1 lb)
- 0.6 kg (1.2 lb)
- 0.6 kg (1.2 lb)
- 0.5 kg (1.1 lb)
- 0.6 kg (1.2 lb)
- 0.6 kg (1.2 lb)
Environment
-
Ingress Protection
UNO-2271G-E21BE IP30 UNO-2271G-E22BE IP30 UNO-2271G-E23BE IP30 UNO-2271G-E021AE IP30 UNO-2271G-E022AE IP30 UNO-2271G-E023AE IP30 -
Operating Temperature
UNO-2271G-E21BE 0~50 °C (32~122 °F) UNO-2271G-E22BE 0~50 °C (32~122 °F) UNO-2271G-E23BE 0~50 °C (32~122 °F) UNO-2271G-E021AE 0~50 °C (32~122 °F) UNO-2271G-E022AE 0~50 °C (32~122 °F) UNO-2271G-E023AE 0~50 °C (32~122 °F) -
Relative Humidity
UNO-2271G-E21BE 10~95% RH (non-condensing) UNO-2271G-E22BE 10~95% RH (non-condensing) UNO-2271G-E23BE 10~95% RH (non-condensing) UNO-2271G-E021AE 10~95% RH (non-condensing) UNO-2271G-E022AE 10~95% RH (non-condensing) UNO-2271G-E023AE 10~95% RH (non-condensing) -
Shock Protection
UNO-2271G-E21BE 50 G, half sine UNO-2271G-E22BE 50 G, half sine UNO-2271G-E23BE 50 G, half sine UNO-2271G-E021AE 50 G, half sine UNO-2271G-E022AE 50 G, half sine UNO-2271G-E023AE 50 G, half sine -
Storage Temperature
UNO-2271G-E21BE -20~70 °C (-4~158 °F) UNO-2271G-E22BE -20~70 °C (-4~158 °F) UNO-2271G-E23BE -20~70 °C (-4~158 °F) UNO-2271G-E021AE -20~70 °C (-4~158 °F) UNO-2271G-E022AE -20~70 °C (-4~158 °F) UNO-2271G-E023AE -20~70 °C (-4~158 °F) -
Vibration Protection
UNO-2271G-E21BE 2 Grms, random UNO-2271G-E22BE 2 Grms, random UNO-2271G-E23BE 2 Grms, random UNO-2271G-E021AE 2 Grms, random UNO-2271G-E022AE 2 Grms, random UNO-2271G-E023AE 2 Grms, random
Hardware
-
Certification
UNO-2271G-E21BE CE, FCC, UL, CCC, BSMI UNO-2271G-E22BE CE, FCC, UL, CCC, BSMI UNO-2271G-E23BE CE, FCC, UL, CCC, BSMI UNO-2271G-E021AE CE, FCC, UL, CCC, BSMI UNO-2271G-E022AE CE, FCC, UL, CCC, BSMI UNO-2271G-E023AE CE, FCC, UL, CCC, BSMI -
CPU
UNO-2271G-E21BE Intel® ATOM E3815 1.46GHz Single-Core UNO-2271G-E22BE Intel® ATOM E3815 1.46GHz Single-Core UNO-2271G-E23BE Intel® ATOM E3815 1.46GHz Single-Core UNO-2271G-E021AE Intel® Celeron E3825 1.33 Ghz Dual-Core UNO-2271G-E022AE Intel® Celeron E3825 1.33 Ghz Dual-Core UNO-2271G-E023AE Intel® Celeron E3825 1.33 Ghz Dual-Core -
Graphics Engine
UNO-2271G-E21BE Intel® HD Graphics UNO-2271G-E22BE Intel® HD Graphics UNO-2271G-E23BE Intel® HD Graphics UNO-2271G-E021AE Intel® HD Graphics UNO-2271G-E022AE Intel® HD Graphics UNO-2271G-E023AE Intel® HD Graphics -
Memory
UNO-2271G-E21BE 1 x Onboard Memory with 4 GB DDR3L 1066 MHz UNO-2271G-E22BE 1 x Onboard Memory with 4 GB DDR3L 1066 MHz UNO-2271G-E23BE 1 x Onboard Memory with 4 GB DDR3L 1066 MHz UNO-2271G-E021AE 1 x Onboard Memory with 4 GB DDR3L 1066 MHz UNO-2271G-E022AE 1 x Onboard Memory with 4 GB DDR3L 1066 MHz UNO-2271G-E023AE 1 x Onboard Memory with 4 GB DDR3L 1066 MHz -
OS Support
UNO-2271G-E21BE Microsoft® Windows 10 2019 LTSC, WES7, Linux UNO-2271G-E22BE Microsoft® Windows 10 2019 LTSC, WES7, Linux UNO-2271G-E23BE Microsoft® Windows 10 2019 LTSC, WES7, Linux UNO-2271G-E021AE Microsoft® Windows 10 2019 LTSC, WES7, Linux UNO-2271G-E022AE Microsoft® Windows 10 2019 LTSC, WES7, Linux UNO-2271G-E023AE Microsoft® Windows 10 2019 LTSC, WES7, Linux -
Power Input
UNO-2271G-E21BE 10~30 VDC UNO-2271G-E22BE 10~30 VDC UNO-2271G-E23BE 10~30 VDC UNO-2271G-E021AE 10~30 VDC UNO-2271G-E022AE 10~30 VDC UNO-2271G-E023AE 10~30 VDC -
Storage
UNO-2271G-E21BE 32 GB eMMC, 1 x mSATA (shared with mPCIe) UNO-2271G-E22BE 32 GB eMMC, 1 x mSATA (shared with mPCIe) UNO-2271G-E23BE 32 GB eMMC, 1 x mSATA (shared with mPCIe) UNO-2271G-E021AE 32 GB eMMC, 1 x mSATA (shared with mPCIe) UNO-2271G-E022AE 32 GB eMMC, 1 x mSATA (shared with mPCIe) UNO-2271G-E023AE 32 GB eMMC, 1 x mSATA (shared with mPCIe)
I/O Interface
-
Displays
UNO-2271G-E21BE 1 x HDMI UNO-2271G-E22BE 1 x HDMI UNO-2271G-E23BE 1 x HDMI UNO-2271G-E021AE 1 x HDMI UNO-2271G-E022AE 1 x HDMI UNO-2271G-E023AE 1 x HDMI -
Expansion
UNO-2271G-E21BE 1 x Full-size mPCIe Slot UNO-2271G-E22BE 1 x Full-size mPCIe Slot UNO-2271G-E23BE 1 x Full-size mPCIe Slot UNO-2271G-E021AE 1 x Full-size mPCIe Slot UNO-2271G-E022AE 1 x Full-size mPCIe Slot UNO-2271G-E023AE 1 x Full-size mPCIe Slot -
LAN Ports
UNO-2271G-E21BE 2 x 10/100/1000 Mbps UNO-2271G-E22BE 2 x 10/100/1000 Mbps UNO-2271G-E23BE 2 x 10/100/1000 Mbps UNO-2271G-E021AE 2 x 10/100/1000 Mbps UNO-2271G-E022AE 2 x 10/100/1000 Mbps UNO-2271G-E023AE 2 x 10/100/1000 Mbps -
Power Connector
UNO-2271G-E21BE 1 x 2-Pin Terminal Block UNO-2271G-E22BE 1 x 2-Pin Terminal Block UNO-2271G-E23BE 1 x 2-Pin Terminal Block UNO-2271G-E021AE 1 x 2-Pin Terminal Block UNO-2271G-E022AE 1 x 2-Pin Terminal Block UNO-2271G-E023AE 1 x 2-Pin Terminal Block -
USB Ports
UNO-2271G-E21BE 1 x USB 3.0 UNO-2271G-E22BE 3 x USB 2.0, 1 x USB 3.0 UNO-2271G-E23BE 1 x USB 3.0 UNO-2271G-E021AE 1 x USB 3.0 UNO-2271G-E022AE 3 x USB 2.0, 1 x USB 3.0 UNO-2271G-E023AE 1 x USB 3.0 -
Serial Ports
UNO-2271G-E21BE - UNO-2271G-E22BE - UNO-2271G-E23BE 2 x RS 232/422/485 UNO-2271G-E021AE - UNO-2271G-E022AE - UNO-2271G-E023AE 2 x RS 232/422/485
Mechanical
-
Dimension (W x H x D)
UNO-2271G-E21BE 100 x 70 x 30 mm UNO-2271G-E22BE 100 x 70 x 60 mm UNO-2271G-E23BE 100 x 70 x 60 mm UNO-2271G-E021AE 100 x 70 x 30 mm UNO-2271G-E022AE 100 x 70 x 60 mm UNO-2271G-E023AE 100 x 70 x 60 mm -
Enclosure
UNO-2271G-E21BE Aluminum housing UNO-2271G-E22BE Aluminum housing UNO-2271G-E23BE Aluminum housing UNO-2271G-E021AE Aluminum housing UNO-2271G-E022AE Aluminum housing UNO-2271G-E023AE Aluminum housing -
Weight (Net)
UNO-2271G-E21BE 0.5 kg (1.1 lb) UNO-2271G-E22BE 0.6 kg (1.2 lb) UNO-2271G-E23BE 0.6 kg (1.2 lb) UNO-2271G-E021AE 0.5 kg (1.1 lb) UNO-2271G-E022AE 0.6 kg (1.2 lb) UNO-2271G-E023AE 0.6 kg (1.2 lb)
/AWS-IoT-Greengrass20230617111241.png)
Featured Highlights
-
Modular Box Platforms
Advantech’s UNO series products are box platforms that feature a modularized design and are available with options for single stack or stack-up version. These platforms offer high flexibility and time-to-market support for a variety of applications. The single-stack UNO model provides basic functionality while enable further expansion capability.
