- Panel mount version with reserve side screwing studs
- Positive tactile feedback
- Key emboss frame
- Integrated capacitive touchpad
- Chemical, abrasion and scratch resistant frontsheet
- Resistant to dirt, dust and liquid (IP65)
Product Specifications
- Part Number
- Details
-
XKB-I88T-EA5U-I1
- Industrial or Medical
- Manufacturer
- Number of Keys
- Current Input
- Keyswitch Technology
- Operating Force
- Switch Travel
- Switching Cycles
- Protection Level (max)
- Cover
- Housing Design
- Housing Material
- Mounting Type
- Interfaces
- Operating Temperature
- Storage Temperature
- TouchPad Specification
- TouchPad Resolution
- Trackball Diameter
- Dimension ( W x H x D)
- Weight
- Warranty
- Industrial
- InduKey
- 88
- N/A
- Short travel keys
- 2.6 N
- 0.3 mm
- Approx. 3 mil. (per key)
- IP65 (Front)
- Foil (Robust polyester front foil with key embossment)
- Aluminium
- Aluminium
- Front panel with threaded bolts
- USB
- 0 ~ 70 °C ( 32 ~ 158 °F )
- -25 ~ 80 °C ( -13 ~ 176 °F )
- Capacitive
- N/A
- N/A
- 7.08 x 1.01 x 14.56 inches / 179.8 x 25.7 x 369.8 mm
- 1 kg ( 2.2 lbs)
- 2 years
Keyboard
-
Industrial or Medical
XKB-I88T-EA5U-I1 Industrial -
Manufacturer
XKB-I88T-EA5U-I1 InduKey -
Number of Keys
XKB-I88T-EA5U-I1 88 -
Current Input
XKB-I88T-EA5U-I1 N/A -
Keyswitch Technology
XKB-I88T-EA5U-I1 Short travel keys -
Operating Force
XKB-I88T-EA5U-I1 2.6 N -
Switch Travel
XKB-I88T-EA5U-I1 0.3 mm -
Switching Cycles
XKB-I88T-EA5U-I1 Approx. 3 mil. (per key) -
Protection Level (max)
XKB-I88T-EA5U-I1 IP65 (Front) -
Cover
XKB-I88T-EA5U-I1 Foil (Robust polyester front foil with key embossment) -
Housing Design
XKB-I88T-EA5U-I1 Aluminium -
Housing Material
XKB-I88T-EA5U-I1 Aluminium -
Mounting Type
XKB-I88T-EA5U-I1 Front panel with threaded bolts -
Interfaces
XKB-I88T-EA5U-I1 USB -
Operating Temperature
XKB-I88T-EA5U-I1 0 ~ 70 °C ( 32 ~ 158 °F ) -
Storage Temperature
XKB-I88T-EA5U-I1 -25 ~ 80 °C ( -13 ~ 176 °F ) -
TouchPad Specification
XKB-I88T-EA5U-I1 Capacitive -
TouchPad Resolution
XKB-I88T-EA5U-I1 N/A -
Trackball Diameter
XKB-I88T-EA5U-I1 N/A -
Dimension ( W x H x D)
XKB-I88T-EA5U-I1 7.08 x 1.01 x 14.56 inches / 179.8 x 25.7 x 369.8 mm -
Weight
XKB-I88T-EA5U-I1 1 kg ( 2.2 lbs) -
Warranty
XKB-I88T-EA5U-I1 2 years
