Module RS-485 I/O: ADAM-4000

Các mô-đun I/O RS-485 của Advantech, dòng ADAM-4000, là sự lựa chọn hoàn hảo để thiết lập một hệ thống I/O từ xa với chi phí hợp lý. Khách hàng có thể hưởng lợi từ mô-đun ADAM-4000 nhờ hệ thống dây đơn giản, chỉ sử dụng hai dây để giao tiếp với bộ điều khiển hoặc các thiết bị RS-485 khác. Các mô-đun ADAM-4000 sử dụng giao thức giao tiếp EIA RS-485; đường truyền dữ liệu cân bằng, hai chiều, được sử dụng rộng rãi nhất trong ngành cũng phù hợp với môi trường công nghiệp.

RS-485 Serial I/O: ADAM-4000/4100 Series

The ADAM-4000/ 4100 series featuring rugged industrial-grade cases are specially designed for reliable operation in harsh environments. Built-in microprocessors independently provide intelligent signal conditioning, analog I/O, digital I/O, data display, and RS-485 communication through Modbus RTU protocols.


Feature Highlights

The Most Used Modbus RTU Protocol for Industrial Automation Development

  • Standardized Protocol

    One of the most widely used standard communication protocols for eAutomation development

  • Centralized Control

    Universal remote I/O modules to operate the system via Modbus

    Provides the sample code and command for users to program

  • Easy Integration

Non-Stop Monitoring with Watchdog Timer and Protection

  • Noise Protection

    Data accuracy assured by enhanced ESD/ EFT/ Surge Protection

  • Module Stability Ensured

    Once a problem is detected, the Watchdog Timer automatically recovers the system

  • Save on Maintenance Costs

    The Watchdog Timer enhances system stability and reduces maintenance costs

Multiple Interfaces Integrated with Embedded or PLC Systems via USB or RS-485

  • Friendly L-Shaped Cable Design*

    Users can optionally order the 90 degree micro USB to a Type-A USB cable with a locking mechanism to provide a stable connection

  • Micro USB Interface*

    The new ADAM-4100 series can be powered and transmit data via micro USB interface

    * Only featured on the B version of ADAM-4100 series selected models


FAQ: How to Select the Right Remote I/O for Your Industrial Applications?

The article will take you through step-by-step beginning with an analysis of the advantages of Remote I/O, its physical interfaces, protocols, and I/O functions to choose the right Remote I/O that suits your industrial needs.


Advantech IoT Academy

ADAM-4000/4100 Series: Robust Serial RS-485 Remote I/O

Learn about the advantages of ADAM-4000/4100 series and their applications in the IoT Academy course.

Take course



Technical Training of How to Configure ADAM Remote I/O Modules

This course will introduce the knowledge and necessary skills for using ADAM-4000/4100/6000/6200/6300 Series Modules as Data Acquisition device.

Take course



Quick Find

  • Analog Input

    • Channels

    • Input Range

    • Resolution(Bits)

    • Sampling Rates(S/s)

  • Analog Output

    • Channels

    • Output Ranges

    • Resolution

  • Counter/Encoder Input

    • Channels

  • Digital Input

    • Channels

    • Input Voltage

  • Digital Output

    • Channels

  • Environment

    • Operating Temperature

  • Isolated Digital Input

    • Channels

  • Isolated Digital Output

    • Channels

  • Relay Output

    • Channels

  • RTD Input

    • Channels

  • Thermocouple Input

    • Channels

22 total products

Part Number Description Analog Input Analog Output Counter/Encoder Input Digital Input Digital Output Environment Isolated Digital Input Isolated Digital Output Relay Output RTD Input Thermocouple Input
    Channels Input Range Resolution(Bits) Sampling Rates(S/s) Channels Output Ranges Resolution Channels Channels Input Voltage Channels Operating Temperature Channels Channels Channels Channels Channels
Part Number Description Analog Input Analog Output Counter/Encoder Input Digital Input Digital Output Environment Isolated Digital Input Isolated Digital Output Relay Output RTD Input Thermocouple Input
    Channels Input Range Resolution(Bits) Sampling Rates(S/s) Channels Output Ranges Resolution Channels Channels Input Voltage Channels Operating Temperature Channels Channels Channels Channels Channels
ADAM-4015-F 6-Ch RTD Module w/ Modbus N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A N/A 6 N/A
ADAM-4017+-F 8-Ch AI Module w/ Modbus 8 ±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V, 0~150 mV, 0~500 mV, 0~1 V, 0~5 V, 0~10 V, 0~20 mA, 4~20 mA, ±20 mA 16-bit 10 S/s (sum) N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A N/A N/A N/A
ADAM-4017-F 8-Ch AI Module 8 ±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V, 0~20mA, ±20 mA, 0~150 mV, 0~500 mV, 0~1 V, 0~5 V, 0~10 V 16-bit 10 S/s (sum) N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A N/A N/A N/A
ADAM-4018+-F 8-Ch Thermocouple Input Module w/ Modbus N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A N/A N/A 8
ADAM-4019+-F 8-Channel Universal Analog Input Module N/A ±100 mV, ±500 mV, ±1 V, ±2.5 V, ±5 V, ±10 V, 0~20mA, 4 ~ 20 mA, ±20 mA, 0~100 mV, 0~500 mV, 0~1 V, 0~2.5 V, 0~5 V, 0~10 V N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A N/A N/A 8
ADAM-4021-F 1AO RS-485 Modbus Remote I/O N/A N/A N/A N/A 1 0~10 V, 0~20 mA, 4~20 mA 12-bit N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A N/A N/A N/A
ADAM-4024-B1E 4AO/4DI Modbus RS-485 Remote I/O N/A N/A N/A N/A 4 ±10 V, 0~20 mA, 4~20 mA 12-bit N/A 4 (Isolated) Wet Contact Logic level 1: 10~30 VDC Logic level 0: 0~1 VDC N/A -10~70 °C (14~158 °F) N/A N/A N/A N/A N/A
ADAM-4050-F 16-Ch DI/O Module w/ Modbus N/A N/A N/A N/A N/A N/A N/A N/A 8 Wet Contact Logic level 1: 3.5~30 VDC Logic level 0: 0~1 VDC 8 -10~70 °C (14~158 °F) N/A N/A N/A N/A N/A
ADAM-4051-C 16-Ch Isolated DI Module w/ LED & Modbus N/A N/A N/A N/A N/A N/A N/A N/A 16 (Isolated) N/A N/A -10~70 °C (14~158 °F) N/A N/A N/A N/A N/A
ADAM-4052-BE 8DI RS-485 Remote I/O N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) 8 N/A N/A N/A N/A
ADAM-4053-F 16-Ch Isolated DI Module w/ Modbus N/A N/A N/A N/A N/A N/A N/A N/A 16 Dry contact Logic level 0: close to GND Logic level 1: open Wet contact Logic level 0: 2 VDC max. Logic level 1: 4~30 VDC N/A -10~70 °C (14~158 °F) N/A N/A N/A N/A N/A
ADAM-4055-C 16-Ch Isolated DI/DO Module w/ LED & Modbus N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) 8 8 N/A N/A N/A
ADAM-4056SO-B 12-Ch Source Type Isolated DO Module w/ Modbus N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A 12 N/A N/A N/A
ADAM-4060-F 4-Ch Relay Output Module w/ Modbus N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A 4 N/A N/A
ADAM-4068-C 8-Ch Relay Output Module w/ Modbus N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A 8 N/A N/A
ADAM-4069-B 8-Ch Power Relay Output Module w/ Modbus N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -10~70 °C (14~158 °F) N/A N/A 8 N/A N/A
ADAM-4080-E 2Counter Modbus RS-485 Remote I/O N/A N/A N/A N/A N/A N/A N/A 2 N/A N/A N/A -10~70 °C (14~158 °F) N/A 2 N/A N/A N/A
ADAM-4115-C Robust 6-Ch RTD Input Module N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -40~85 °C (-40~185 °F) N/A N/A N/A 6 N/A
ADAM-4117-C 8-Ch AI Module 8 ±15 V, ±10 V, ±5 V, ±1V, ±0.5 V, ±0.15 V, 0~15 V, 0~10 V, , 0~5 V, 0~1 V, 0~0.5 V, 0~0.15 V, ±20 mA, 4~20 mA, 0~20 mA 16-bit 100 S/s (sum) N/A N/A N/A N/A N/A N/A N/A -40~85 °C (-40~185 °F) N/A N/A N/A N/A N/A
ADAM-4118-C 8-Ch Thermocouple Input Module N/A ±15 mV, ±50 mV, ±100 mV, ±500 mV, ±1 V, ±2.5 V, 0~15 mV, 0~50 mV, 0~100 mV, 0~500 mV, 0~1 V, 0~2.5 V N/A N/A N/A N/A N/A N/A N/A N/A N/A -40~85 °C (-40~185 °F) N/A N/A N/A N/A 8
ADAM-4150-C 15-Ch DI/O Module N/A N/A N/A N/A N/A N/A N/A 7 N/A N/A N/A -40~85 °C (-40~185 °F) 7 8 N/A N/A N/A
ADAM-4168-C 8-Ch Relay Output Module N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A -40~85 °C (-40~185 °F) N/A N/A 8 N/A N/A

Product Categories

  • Module Analog I/O

    Các mô-đun đầu vào analog cung cấp các nguồn đầu vào khác nhau, chẳng hạn như cặp nhiệt điện (thermocouple), RTD, nhiệt điện trở (thermistor) hoặc tín hiệu analog chung. Các mô-đun này sử dụng giao thức truyền thông EIA RS-485 - tiêu chuẩn đường truyền cân bằng hai chiều, được sử dụng rộng rãi trong ngành công nghiệp. ADAM-4000 cũng hỗ trợ giao thức Modbus/RTU như một cơ chế truyền dữ liệu từ xa.

  • Module Digital I/O

    Các module đầu ra/đầu ra kỹ thuật số (digital input/output) ADAM-4000 Series của Advantech được trang bị 24-channel mật độ cao, cách ly, bảo vệ đoản mạch, chức năng bảo vệ lỗi và chức năng chuyển đổi nhanh (hot-swap) để tăng tỷ lệ sử dụng module đầu vào/đầu ra kỹ thuật số ADAM-4000 này và cung cấp một hệ thống đáng tin cậy.
